Facilities

Chroma Systems Solutions, Inc. Headquarters

Located in Foothill Ranch, CA, our headquarters includes a staff of engineers that can help to plan and assemble a testing and automation solution customized for any application. In addition to our engineers, we provide a complete service department for our instruments and systems, and also have software engineers on hand to train or assist with the automation software that accompanies many of our products.

Chroma Systems Solutions Main Offices

East Coast Regional Offices

Located in Marlborough, MA, our East Coast offices are staffed with sales and service personnel for our range of safety testing instrumentation.

Central and South American Regional Offices

Located in Mexico, our Central and South American offices are staffed with sales personnel for our full range of testing instrumentation.

Chroma ATE Inc.

Founded in 1984, Chroma ATE Inc. is a world leading supplier of precision Test and Measurement Instrumentation, Automated Test Systems, Manufacturing Execution Systems and Turnkey Test and Automation Solutions marketed globally under the brand name “Chroma”.

Taoyuan Factory

Production Space:
142,330 ft2 (Four stories)

Assembly Line:
AI Line, SMD Line, PCBA Line, Module Line, Cabinet System Line, Mechatronics System Line

Kaohsiung Factory

Production Space:
106,750 ft2 (Two stories)

Assembly Line:
Mechatronics System Line

Shenzhen Factory

Production Space:
35,500 ft2 (One story)

Assembly Line:
Module Assembly Line

SMT Line

Equipment:

  • Screen Printer
  • Adhesive Dispenser
  • Compact-Sized Chip Mounter
  • Compact-Sized Fine-Pitch Mounter
  • AOI Inspection
  • N2 Reflow Oven
  • PCB Size

    • Line2 : Max:460*360mm
    • Line1 : Max:750*460mm
  • Range of Component s

    • Line1 : 0603 (0201″) Chip ~ □43mm ~ Φ150mm
    • Line2 : 0402 (01005″) Chip ~ □74mm or 50x150mm
  • Placement tact time (Each M/C)

    • Line1 : Chip 18,000 CPH、IC 2,400 CPH
    • LIne2 : Chip 23,300 CPH、IC 4,860 CPH
  • Reflow

    • Line1 : 10 Heat Zones , 3 Cooling Zones
    • Line2 : 11 Heat Zones , 2 Cooling Zones

AI Line

Equipment:

  • Component Sequencer
  • Component Inserter
  • PCB Size Max:480*400mm
  • Insertion rates: 25000 CPH

Inspection

Equipment:

  • Equipment : X-Ray
  • Maximum current:1000uA
  • Detail detect ability:down to 1 micron

DIP Line

CHROMA is a renowned global instrument manufacturer and its affiliated Calibration Laboratory is recognized by the Taiwan Accreditation Foundation (TAF) with an ISO/IEC 17025 accreditation.

CHROMA has complete laboratory facilities for test and calibration of equipment.
